Light Pump Plaster sprayer

Uses

  • Indoor and outdoor plasters
  • Calcium and gypsum based plasters
  • Thermal insulation glue
  • Thermal plasters
  • Thermal insulation
  • Self-levelling floor screeds
  • Joints filling

    • Description

    Mac-Edil, focused on markets requirements, which often and often demands the use of special thermal insulation materials, has developed Light pump: to lay thermal insulation glue, pre-mixed and finishing plasters. It is small and compact, in order to be handy in reduced spaces and let the operator move easily, however granting high performance.
    Completely galvanised to protect it from weather conditions, it is equipped with electric panel and inverter, to guarantee the widest range of flow rate and high performance .

    Size

    Loading height
    1150 mm
    Width
    520 mm
    Length
    1330 mm
    Weight
    130 kg

    TECHNICAL FEATURES

    Voltage
    230V 50/60Hz
    Power
    2,2 kW
    Inverter
    Yes
    Flow rate
    5-16 l/min
    Capacity
    50 l
    Pumping distance
    max 25 mt
    Grain size
    3mm*
    * Orientative grain size, according to quality and material composition

    Standard equipment - thermal insulation glues

    15-meter grout tube with air tube and control
    One-head compressor
    Electric board with inverter
    Water unit with pump
    Glue gun with spray head
    Complete stator
    Supply envelope and keys
    Use and maintenance manual
    Declaration of conformity

    Standard equipment - Plasters

    15-meter grout tube with air tube and control
    One-head compressor
    Electric board with inverter
    Water unit with pump
    Plaster gun
    Complete stator
    Supply envelope and keys
    Use and maintenance manual
    Declaration of conformity

    options

    Compressor for finishing works 350 l/min 3HP
    Finishing spray head
    Filling set
